110W Open Array Radar with 6’ Antenna!
Raymarine's Cyclone Pro series of radars gives you the confidence to take on the harshest of marine conditions while maintaining a high sense of situational awareness. Easily scan the open ocean looking for flocks of schooling birds or navigate a busy waterway with the high performance, solid-state CHIRP, pulse compression style cyclone radar.
The advanced Cyclone Pro open array radar comes with a 6’ open array offering a beamwidth of 1.32°. The 110W of power output is comparable to a 12KW, magnetron style radar. Each Model of the cyclone features innovative detection technologies including the cyclone bird mode putting the Cyclone in a category of its own.
Don’t let the beauty and sleekness of the Cyclone Pro series fool you. This radar was designed and engineered using the same profiles as an aircraft to withstand wind speeds of over 100 knots! The 60-RPM rotational speed provides a full 360-degree scan of accurate arpa tracking for up to 50 targets in real time.
Raymarine’s RangeFusion technology merges short-pulse, near target ranges with long-pulse, distant target ranges that create a single radar image that is much easier to interpret than what we’re all used to.
A Captain’s awareness level while on the water is key in making sure everyone on board is safe. The Cyclone pro can be a key element in supporting this by making sure the Captain detects buoys, markers, other vessels, and some types of floating debris.
Pair the Cyclone Pro with one of Raymarine’s state of the art Axiom series MFD’s to unlock the max performance of Solid State, CHIRP, Pulse Compression radar that you’ve been missing out on!
Raymarine Cyclone Pro 110W Radar with 6' Open Array Key Features
- Solid State Open Array
- Provide Superior target separation
- Cyclone Bird Mode
- High Speed 60 RPM Imaging
- Low Profile and Aircraft Wing Inspired
- Pedestal Size: 15.27"W x 14.17"H x 13.18“D
- Array Size: 76.59” in Length
Raymarine Cyclone Pro 110W Radar with 6' Open Array Box Contents
Each Raymarine Cyclone Pro 110W Radar with 6' Open Array Comes with:
- Pedestal
- M10 Stud(x4), Nut(x8),Spring Washer(x4)Plain Washer x4
- Mounting Gasket and Template
- Radar Data Cable
- Power Cable
- Antenna
- Threaded Alignment Guide
- Washer, Spring Washer and Nut
- VCM100 with Cable Clamp and Screws
- Up to a 3 Year Warranty
Raymarine Cyclone 110W Radar with 6' Open Array Key Features
- Solid State Open Array
- Provide Superior target separation
- Cyclone Bird Mode
- High Speed 60 RPM Imaging
- Low Profile and Aircraft Wing Inspired
- Pedestal Size: 15.27"W x 14.17"H x 13.18“D
- Array Size: 76.59” in Length
Raymarine Cyclone Manual- Click Here
