Garmin AIS 800 Automatic Identification System Transceiver

Free Ground Shipping!

Garmin AIS 800 Automatic Identification System Transceiver

Garmin AIS 800 Automatic Identification System Transceiver

Send and receive important vessel information with Garmin’s AIS 800. 5W Transmit power with Class B/SO provides quicker position reporting than ever before! Built in GPS and Internal VHF Antenna Splitter allowing use of a single antenna for AIS and VHF.
  • SKUGA02087
  • MAN#010-02087-00
  • ID#: 5622
(Rating 92)
Our Price:
$799.95
Availability:
In Stock
Shipping:
Free Ground Shipping!
Condition:
Brand New

Enhance Situational Awareness on the Water

Situational Awareness is key when on the open water, and with Garmin's AIS 800 transceiver being aware of your surroundings is easier than ever before. 5 watts of transmitting power with Class B/SO position provides fast position reporting. Simultaneously sending your AIS position with vessel data while also receiving the position and data of vessels in your area ensures your know what's headed your way!

NMEA 2000/0183 connectivity makes connecting to your NMEA network a breeze. Choose from plug and play system with NMEA2000 or a bare wire connection via NMEA0183. An internal VHF splitter allows the AIS 800 to share a single VHF antenna with an existing VHF radio and also includes an internal GPS receiver with a connection for optional external GPS receiver. The AIS 800 comes with a VHF interconnect cable (1.2 meters) which enables you to connect the AIS 800 to a VHF radio and share a single VHF antenna. Simple to install and with a small footprint the AIS 800 is a top choice in AIS Transceivers.


* Before we can program your AIS we need a few pieces of information and all AIS units require programming before shipping. Please fill out the form below and fax (910-575-9543) or email (sales@thegpsstore.com) it back to us.
Click here to download a copy of the AIS programming form.
You will also need an MMSI number to complete the above form, if you don't already have one, you can get that here.


Replaces Garmin AIS600 (AIS 600), 010-01865-00.

Garmin AIS 800 Transceiver Box Contents
Each AIS 800 Transceiver Comes with:
  • AIS 800
  • NMEA 2000® T-connector
  • NMEA 2000 drop cable (2 meters)
  • VHF antenna extension (1.2 meters)
  • USB adapter cable
  • Power cable
  • Mounting hardware
  • Documentation
  • Two Year Warranty
Garmin AIS 800 Transceiver Key Features
  • 5W Transmit Power with Class B/SO
  • NMEA 2000 Connectivity
  • Built-In GPS Receiver with connector for external antenna
  • Internal VHF Antenna Splitter enables a single antenna to be used for VHF/AIS
  • Send and Receive AIS Data
  • Size: 6.9"W x 5.6 "H x 2.2“D
